socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC

Item ID #SSLZRA1

Schneider Electric

socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC

Name: socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC
Brand: Schneider Electric
SKU: SSLZRA1
Price: 17.70 CAD
Availability: OutOfStock

Item ID #SSLZRA1

Specifications

See all specifications

Height :	101 mm
[Uimp] Rated Impulse Withstand Voltage :	3.6 kV
Clamping Force :	10-40 N

EZ Selector

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

"This Harmony SSL socket for solid state slim interfacing relay has spring terminals and a rated voltage of 5V DC." "It also offers clear circuit labelling on the sides to facilitate installation and maintenance." "It features a visual indicator LED for a simpler troubleshooting and commissioning." "Its clear schematic on the side of the socket enables easier wiring and maintenance." 0 0 0 0 0 0 0 0 0 0 0 0

Recommended tools

Complementary


Height :	101 mm
[Uimp] Rated Impulse Withstand Voltage :	3.6 kV
Clamping Force :	10-40 N
Pollution Degree :	3
Shape Of Pin :	flat
Contact Terminal Arrangement :	separate
Net Weight :	0.0285 kg
Fixing Mode :	clip-on (35 mm DIN rail)
Connections - Terminals :	spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end \|\| spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end
Sale Per Indivisible Quantity :	10
Local Signalling :	for input status LED (green)
Width :	6.2 mm
Overvoltage Category :	III
Depth :	78.6 mm

Description
Resources
Specifications

socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC

Item ID #SSLZRA1

Schneider Electric

socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC

Item ID #SSLZRA1

socket equipped with LED and protection circuit, Harmony Solid State Relays, for SSL relays, spring terminals, 5 to 24V DC

Specifications

See all specifications

Height :	101 mm
[Uimp] Rated Impulse Withstand Voltage :	3.6 kV
Clamping Force :	10-40 N

EZ Selector

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

Recommended tools

Complementary


Height :	101 mm
[Uimp] Rated Impulse Withstand Voltage :	3.6 kV
Clamping Force :	10-40 N
Pollution Degree :	3
Shape Of Pin :	flat
Contact Terminal Arrangement :	separate
Net Weight :	0.0285 kg
Fixing Mode :	clip-on (35 mm DIN rail)
Connections - Terminals :	spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end \|\| spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end
Sale Per Indivisible Quantity :	10
Local Signalling :	for input status LED (green)
Width :	6.2 mm
Overvoltage Category :	III
Depth :	78.6 mm


Product Certifications :	UL 508 \|\| CSA C22-2 No 14
Ambient Air Temperature For Operation :	-40-70 °C
Standards :	IEC 61984
Marking :	CE
Flame Retardance :	V0 conforming to UL 94
Ambient Air Temperature For Storage :	-40-85 °C
Ip Degree Of Protection :	IP20


Width :	6.2 mm
Height :	101 mm
Weight :	0.0285 kg
[Ith] Conventional Free Air Thermal Current :	6 A
Range Of Product :	Harmony Solid State Relays
Product Or Component Type :	socket for SSL1
Product Compatibility :	solid state relay SSL NO 24 V DC \|\| solid state relay SSL NO 5 V DC
Switching Voltage :	5 V DC \|\| 24 V DC
Device Short Name :	SSLZ
[Ue] Rated Operational Voltage :	< 250 V DC


Rohs Exemption Information :	Yes
Mercury Free :	Yes
Environmental Disclosure :	ENVPEP1405004EN
Sustainable Offer Status :	Green Premium product
Toxic Heavy Metal Free :	Yes
Reach Regulation :	Free of Substances of Very High Concern above the threshold
California Proposition 65 :	WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach Free Of Svhc :	Yes
China Rohs Regulation :	X
Circularity Profile :	ENVEOLI1405004EN
Eu Rohs Directive :	Pro-active compliance (Product out of EU RoHS legal scope)
