| Item ID |
|---|
| Title |
| Ambient Air Temperature For Operation : | -25-50 °C |
| Ip Degree Of Protection : | IP20 IEC 60529 |
| Ambient Air Temperature For Storage : | -50-80 °C |
| Ambient Air Temperature For Operation : | -25-50 °C |
| Ip Degree Of Protection : | IP20 IEC 60529 |
| Ambient Air Temperature For Storage : | -50-80 °C |
| Permissible Short-Time Rating : | 80 A 1 s || 60 A 500 ms || 110 A 100 ms |
| Minimum Switching Current : | 5 mA |
| Height : | 30 mm |
| Product Certifications : | CB Scheme || CCC || UL || CSA || CE || UKCA |
| [Ith] Conventional Free Air Thermal Current : | 10 A (at 50 °C) |
| Standards : | EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5 || JIS C8201-5-1 |
| Rohs Exemption Information : | Yes |
| Mercury Free : | Yes |
| Environmental Disclosure : | ENVPEP2106022 |
