| Contacts Type And Composition : | NO relay output |
| Input Impedance : | 350 kOhm discrete input |
| Discrete Input Frequency : | 57...63 Hz || 47...53 Hz |
| Number Of Outputs : | 4 relay |
| Output Thermal Current : | 8 A for all 4 outputs relay output |
| Discrete Input Voltage : | 100...240 V AC |
| Number Or Control Scheme Lines : | 0-240 ladder || 0-500 FBD |
| Backup Time : | 10 years 25 °C |
| Clock Drift : | 12 min/year 0-55 °C || 6 s/month 25-25 °C |
| Power Consumption In Va : | 7 VA without extension |
| Discrete Input Current : | 0.6 mA |
| Current State 1 Guaranteed : | >= 0.17 mA discrete input) |
| Response Time : | 50 ms ladder from state 0 to state 1)discrete input || 50 ms ladder from state 1 to state 0)discrete input || 50...255 ms FBD from state 0 to state 1)discrete input || 50...255 ms FBD from state 1 to state 0)discrete input || 10 ms from state 0 to state 1)relay output || 5 ms from state 1 to state 0)relay output |
| Clock : | with |
| Local Display : | without |
| Net Weight : | 0.22 kg |
| [Uimp] Rated Impulse Withstand Voltage : | 4 kV EN/IEC 60947-1 and EN/IEC 60664-1 |
| Voltage State 0 Guaranteed : | <= 40 V discrete input |
| Output Voltage Limits : | 5...30 V DC relay output) || 24...250 V AC |
| Electrical Durability : | AC-12 500000 cycles 230 V, 1.5 A relay output IEC 60947-5-1 || AC-15 500000 cycles 230 V, 0.9 A relay output IEC 60947-5-1 || DC-12 500000 cycles 24 V, 1.5 A relay output IEC 60947-5-1 || DC-13 500000 cycles 24 V, 0.6 A relay output IEC 60947-5-1 |
| Connections - Terminals : | screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) semi-solid || screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) solid || screw terminals, 1 x 0.25...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end || screw terminals, 2 x 0.2...2 x 1.5 mm² AWG 24...AWG 16) solid || screw terminals, 2 x 0.25...2 x 0.75 mm² AWG 24...AWG 18) flexible with cable end |
| Analogue Input Number : | 0 |
| Voltage State 1 Guaranteed : | >= 79 V discrete input |
| Current State 0 Guaranteed : | <= 0.5 mA discrete input) |
| Supply Voltage Limits : | 85-264 V |
| Overvoltage Category : | III IEC 60664-1 |
| Mechanical Durability : | 10000000 cycles relay output |
| Maximum Supply Current : | 30 mA 240 V without extension) || 80 mA 100 V without extension) |
| Tightening Torque : | 0.5 N.m |
| Isolation Voltage : | 1780 V |
| Switching Capacity In Ma : | >= 10 mA 12 V relay output) |
| Protection Type : | against inversion of terminals (control instructions not executed) |
| Operating Rate In Hz : | 0.1 Hz at Ie)relay output || 10 Hz no load)relay output |
| Discrete Input Number : | 8 |
| Cycle Time : | 6-90 ms |
| Supply Frequency : | 50/60 Hz |
| [Us] Rated Supply Voltage : | 100...240 V AC |
| Checks : | program memory on each power up |
