Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation :
Reference contains Substances of Very High Concern above the threshold
California Proposition 65 :
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Complementary
Connections - Terminals :
screw clamp terminal, 1 x 0.5...2 x 1.5 mm²
Reset :
by flush push-button
Contacts Type And Composition :
1 NC + 1 NO
Terminals Description Iso N°1 :
(21-22)NC || (13-14)NO
[Ui] Rated Insulation Voltage :
500 V 3)EN/IEC 60947-1 || 300 VUL 508 || 300 VCSA C22.2 No 14
Short-Circuit Protection :
10 A cartridge fuse gG EN/IEC 60269
[Ie] Rated Operational Current :
3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 appendix A || 0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 appendix A
Contact Operation :
slow-break
Distance Between Cable Supports :
5-5 m
Mechanical Durability :
60000 cycles
Positive Opening :
with EN/IEC 60947-5-1
Cable Entry Number :
3 plain hole Pg 13.5 or ISO M20 cable gland
Compatibility Code :
XY2CE
Body Material :
zamak
[Ithe] Conventional Enclosed Thermal Current :
10 A
Trigger Cable Anchor Point :
RH side
Safety Reliability Data :
B10d = 300000 value given for a life time of 20 years limited by mechanical or contact wear IEC 60947-5-5
Marking :
CE
Cover Material :
stainless steel
Local Signalling :
without pilot light
Net Weight :
1.45 kg
Tightening Torque :
0.8-1.2 N.m
[Uimp] Rated Impulse Withstand Voltage :
6 kV EN/IEC 60947-1
Maximum Resistance Across Terminals :
25 MOhm EN/IEC 60255-7 category 3 || 25 MOhm NF C 93-050 method A
Safety Level :
can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 with the appropriate monitoring system and correctly wired EN/IEC 61508
