Head for push button, Harmony XAC, plastic, white, booted, operating travel 16mm, 25...+ 70 degree C

Item ID #XACB9211

Schneider Electric

Head for push button, Harmony XAC, plastic, white, booted, operating travel 16mm, 25...+ 70 degree C

Name: Head for push button, Harmony XAC, plastic, white, booted, operating travel 16mm, 25...+ 70 degree C
Brand: Schneider Electric
SKU: XACB9211
Price: 17.00 CAD
Availability: InStock

Item ID #XACB9211

Specifications

See all specifications

Ik Degree Of Protection :	IK08 conforming to IEC 62262
Ambient Air Temperature For Operation :	-25-70 °C
Standards :	IEC 60947-5-1 \|\| CSA C22.2 No 14

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

This white booted operator is a separate component for double insulated, XACB pendant control station. Its maximum operating travel is equal to 16mm. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65.

Recommended tools

Environment


Ik Degree Of Protection :	IK08 conforming to IEC 62262
Ambient Air Temperature For Operation :	-25-70 °C
Standards :	IEC 60947-5-1 \|\| CSA C22.2 No 14
Shock Resistance :	100 gn IEC 60068-2-27
Vibration Resistance :	15 gn 10-500 Hz)IEC 60068-2-6
Ip Degree Of Protection :	IP65 IEC 60529
Ambient Air Temperature For Storage :	-40-70 °C
Electrical Shock Protection Class :	class II IEC 61140

Available0

Your price

$0.00

Offer Sustainability


Rohs Exemption Information :	Yes
Mercury Free :	Yes
Toxic Heavy Metal Free :	Yes
Reach Regulation :	Free of Substances of Very High Concern above the threshold
Reach Free Of Svhc :	Yes
China Rohs Regulation :	X
Eu Rohs Directive :	Pro-active compliance (Product out of EU RoHS legal scope)

Specifications


Operator Additional Information :	booted
Range Of Product :	Harmony XAC
Product Or Component Type :	head for push-button
Marking :	unmarked
Cap/Operator Or Lens Colour :	white
Component Name :	XACB
Sale Per Indivisible Quantity :	10
Operating Travel :	16 mm
Product Compatibility :	XESD1191 \|\| XESD1291 \|\| XESD1181 \|\| XESD1281
