| Operating Force : | 44 N |
| Short-Circuit Protection : | 10 A cartridge fuse gG IEC 60947-5-1 |
| Operating Travel : | 1.5 mm NC changing electrical state) || 4.3 mm total travel) |
| Contacts Material : | silver alloy (Ag/Ni) |
| Positive Opening : | with IEC 60947-5-1 appendix K |
| [Ith] Conventional Free Air Thermal Current : | 10 A IEC 60947-5-1 |
| Cable Entry : | 1 knock-out for cable entry 0-14 mm || 2 knock-outs for Pg 13 cable gland and ISO M20 0-12 mm |
| Net Weight : | 0.194 kg |
| [Uimp] Rated Impulse Withstand Voltage : | 6 kV IEC 60947-1 |
| Resistance To High Pressure Washer : | 7000000 Pa 55 °C 0.1 m |
| Electrical Durability : | 1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C |
| Connections - Terminals : | screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1 |
| [Ui] Rated Insulation Voltage : | 600 V 3)IEC 60947-1 |
| [Ie] Rated Operational Current : | 3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1 |
| Mechanical Durability : | 300000 cycles |
| Electrical Reliability : | λ < 10exp(-6) 5 V, 1 mA IEC 60947-5-4 || λ < 10exp(-8) 17 V, 5 mA IEC 60947-5-4 |
| Tightening Torque : | 0.8-1.2 N.m IEC 60947-1 |
| Shape Of Screw Head : | cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm |
