| Item ID |
|---|
| Title |
| Height BX (IN) : | 2 |
| Height (mm) : | 67.8688 |
| Length (mm) : | 33.655 |
| Height BX (IN) : | 2 |
| Height (mm) : | 67.8688 |
| Length (mm) : | 33.655 |
| Prop65 Compliance : | This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation |
| UL / CULUS Specification : | UL 467 Listed |
| ILSCOs Die Index Number : | 1011 |
| Conductor Material : | Copper |
| Connector Finish : | Bare |
| Material : | Copper |
| Conductor Range CU Solid (Secondary, tap, load) : | 2 Sol - 6 Sol |
| Conductor Range CU Stranded (Primary, run, main, line) : | 500 kcmil - 300 kcmil |
| Conductor Range CU Stranded (Secondary, tap, load) : | 3/0 Str - 6 Str |
| Conductor Type : | Stranded, Solid |
| Bag Quantity : | 1 |
| Carton Quantity Description : | STD PACK QTY 6 |
| Direct Burial : | Yes |
| Height : | 2.672 in | 67.8688 mm |
| Length : | 1.325 in | 33.655 mm |
| Weight : | 0.505 lbs |
| Color : | Copper |
