| Item ID |
|---|
| Title |
| Voltage Rating : | 600 V |
| Drive Size Main : | 1/2 |
| Drive Type Main : | External Hex |
| Voltage Rating : | 600 V |
| Drive Size Main : | 1/2 |
| Drive Type Main : | External Hex |
| Height BX (IN) : | 2 |
| CSA File Number : | LR-29601 |
| CSA Standard : | C22.2 No. 65-03 |
| Prop65 Compliance : | WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov |
| Connection : | Mechanical |
| Contains DE-OX® : | No |
| Number of Conductors : | 2 |
| Clamping Hardware Finish : | Tin |
| Clamping Hardware Material : | Steel |
| Conductor Material : | Copper, Aluminum |
| Conductor Range AL Stranded (Primary, run, main, line) : | 4/0 Str - 2 Str |
| Conductor Range AL Stranded (Secondary, tap, load) : | 2/0 Str - 6 Str |
| Conductor Range CU Stranded (Primary, run, main, line) : | 4/0 Str - 2 Str |
| Connector Amperage Rating AL (Derated where applicable) : | 150 Amps |
| Connector Amperage Rating CU (Derated where applicable) : | 195 Amps |
| Conductor Type : | Stranded |
| Bag Quantity : | 1 |
| Carton Quantity Description : | STD PACK QTY 8 |
| Direct Burial : | No |
| Height : | 2.858 in | 72.5932 mm |
| Length : | 1.666 in | 42.3164 mm |
| Weight : | 0.257 lbs |
| Clamping Bolt Size : | M8 x 1.25-6g |
| Number of Wire Binding Screws per Port : | 1 |
| Wire Binding Screw Size : | 5/16 |
| Color : | Black |
| Temperature Rating : | 90°C |
