Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic

Item ID #LAL26350

Schneider Electric

Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic

Name: Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic
Brand: Schneider Electric
SKU: LAL26350
Price: 6156.00 CAD
Availability: OutOfStock

Item ID #LAL26350

Specifications

See all specifications

Circuit Breaker Application :	HACR rated
Terminal Identifier :	AL400LA
Height :	11 in

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

Square D FA/LA Molded Case Circuit Breakers is designed to protect electrical systems from damage caused by overloads. For distribution systems supplied by transformers and distribution systems supplied by engine generator sets.

Recommended tools

Complementary


Circuit Breaker Application :	HACR rated
Terminal Identifier :	AL400LA
Height :	11 in
Mounting Mode :	unit mount
Tightening Torque :	13-13 N.m 42-304 mm² AWG 1...600 kcmil) \|\| 13-13 N.m 42-127 mm² AWG 1...250 kcmil)
Magnetic Tripping Current :	3500-3500 A
Poles Description :	2P
[In] Rated Current :	350 A
Width :	6 in
Electrical Connection :	lugs, load \|\| lugs, line
Depth :	5.84 in
Magnetic Hold Current :	1750 A

Description
Resources
Specifications

Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic

Item ID #LAL26350

Schneider Electric

Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic

Item ID #LAL26350

Circuit breaker, LA, 350A, 2 pole, 600VAC, 22kA, 250VDC, 10kA, lugs, thermal magnetic

Specifications

See all specifications

Circuit Breaker Application :	HACR rated
Terminal Identifier :	AL400LA
Height :	11 in

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

Recommended tools

Complementary


Circuit Breaker Application :	HACR rated
Terminal Identifier :	AL400LA
Height :	11 in
Mounting Mode :	unit mount
Tightening Torque :	13-13 N.m 42-304 mm² AWG 1...600 kcmil) \|\| 13-13 N.m 42-127 mm² AWG 1...250 kcmil)
Magnetic Tripping Current :	3500-3500 A
Poles Description :	2P
[In] Rated Current :	350 A
Width :	6 in
Electrical Connection :	lugs, load \|\| lugs, line
Depth :	5.84 in
Magnetic Hold Current :	1750 A


China Rohs Regulation :	Product out of China RoHS scope. Substance declaration for your information
Circularity Profile :	N/A
Rohs Exemption Information :	Yes
Mercury Free :	Yes
Environmental Disclosure :	ENVPEP1410004EN
Sustainable Offer Status :	Green Premium product
Pvc Free :	Yes
Eu Rohs Directive :	Compliant with Exemptions
Reach Regulation :	Reference contains Substances of Very High Concern above the threshold
Halogen Content Performance :	Halogen free plastic parts product


Trip Unit Technology :	thermal-magnetic
Product Or Component Type :	circuit breaker
