| Item ID |
|---|
| Title |

| Product Certifications : | DNV || CSA || BV || LROS (Lloyds register of shipping) || UL listed || GL |
| Ik Degree Of Protection : | IK04 conforming to IEC 50102 |
| Ambient Air Temperature For Operation : | -40-70 °C |
| Product Certifications : | DNV || CSA || BV || LROS (Lloyds register of shipping) || UL listed || GL |
| Ik Degree Of Protection : | IK04 conforming to IEC 50102 |
| Ambient Air Temperature For Operation : | -40-70 °C |
| Warranty : | 18 months |
| Rohs Exemption Information : | Yes |
| Mercury Free : | Yes |
| Environmental Disclosure : | ENVPEP1710010EN |
| Important Message : | A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks |
| Electrical Composition Code : | M3 4 single front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2 single rear mounting integral LED || M4 4 single and double front mounting integral LED |
| Net Weight : | 0.017 kg |
| Cad Overall Height : | 29 mm |
| Range Of Product : | Harmony XB5 |
| Mounting Diameter : | 22 mm |
| Type Of Operator : | right to left spring return |
