Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals

Item ID #LA1KN20

Schneider Electric

Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals

Name: Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals
Brand: Schneider Electric
SKU: LA1KN20
Price: 16.10 CAD
Availability: OutOfStock

Item ID #LA1KN20

Specifications

See all specifications

Product Certifications :	CB Scheme \|\| CCC \|\| UL \|\| CSA \|\| CE \|\| UKCA
[Ith] Conventional Free Air Thermal Current :	10 A (at 50 °C)
Standards :	EN/IEC 60947-5-1 \|\| UL 60947-5-1 \|\| CSA C22.2 No 60947-5-1 \|\| GB/T 14048.5 \|\| JIS C8201-5-1

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals. It provides 2NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).

Recommended tools

Specifications


Product Certifications :	CB Scheme \|\| CCC \|\| UL \|\| CSA \|\| CE \|\| UKCA
[Ith] Conventional Free Air Thermal Current :	10 A (at 50 °C)
Standards :	EN/IEC 60947-5-1 \|\| UL 60947-5-1 \|\| CSA C22.2 No 60947-5-1 \|\| GB/T 14048.5 \|\| JIS C8201-5-1
[Ue] Rated Operational Voltage :	690 V AC 25...400 Hz
Range Compatibility :	TeSys K LC1K \|\| TeSys K CA2K \|\| TeSys K CA3K \|\| TeSys K CA4K
Product Or Component Type :	auxiliary contact block
Product Name :	TeSys K
Range :	TeSys
Mounting Location :	front
Pole Contact Composition :	2 NO
[Ui] Rated Insulation Voltage :	690 V IEC 60947-5-1 \|\| 600 V UL 60947-5-1 \|\| 600 V CSA C22.2 No 60947-5-1
Auxiliary Contacts Operation :	instantaneous
Device Short Name :	LA1

Description
Resources
Specifications

Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals

Item ID #LA1KN20

Schneider Electric

Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals

Item ID #LA1KN20

Auxiliary contact block, TeSys K, 2NO, front mounting, screw clamp terminals

Specifications

See all specifications

Product Certifications :	CB Scheme \|\| CCC \|\| UL \|\| CSA \|\| CE \|\| UKCA
[Ith] Conventional Free Air Thermal Current :	10 A (at 50 °C)
Standards :	EN/IEC 60947-5-1 \|\| UL 60947-5-1 \|\| CSA C22.2 No 60947-5-1 \|\| GB/T 14048.5 \|\| JIS C8201-5-1

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

Recommended tools

Specifications


Product Certifications :	CB Scheme \|\| CCC \|\| UL \|\| CSA \|\| CE \|\| UKCA
[Ith] Conventional Free Air Thermal Current :	10 A (at 50 °C)
Standards :	EN/IEC 60947-5-1 \|\| UL 60947-5-1 \|\| CSA C22.2 No 60947-5-1 \|\| GB/T 14048.5 \|\| JIS C8201-5-1
[Ue] Rated Operational Voltage :	690 V AC 25...400 Hz
Range Compatibility :	TeSys K LC1K \|\| TeSys K CA2K \|\| TeSys K CA3K \|\| TeSys K CA4K
Product Or Component Type :	auxiliary contact block
Product Name :	TeSys K
Range :	TeSys
Mounting Location :	front
Pole Contact Composition :	2 NO
[Ui] Rated Insulation Voltage :	690 V IEC 60947-5-1 \|\| 600 V UL 60947-5-1 \|\| 600 V CSA C22.2 No 60947-5-1
Auxiliary Contacts Operation :	instantaneous
Device Short Name :	LA1


Rohs Exemption Information :	Yes
Mercury Free :	Yes
Environmental Disclosure :	ENVPEP2106022
Sustainable Offer Status :	Green Premium product
Toxic Heavy Metal Free :	Yes
Reach Regulation :	Free of Substances of Very High Concern above the threshold
Reach Free Of Svhc :	Yes
Weee :	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
China Rohs Regulation :	Pro-active China RoHS declaration (out of China RoHS legal scope)
Circularity Profile :	N/A
Eu Rohs Directive :	Compliant


Permissible Short-Time Rating :	80 A 1 s \|\| 60 A 500 ms \|\| 110 A 100 ms
Minimum Switching Current :	5 mA
Height :	30 mm
Non Overlap Distance :	0.5 mm
Insulation Resistance :	> 10 MOhm
Irms Rated Making Capacity :	110 A at <= 690 V AC conforming to IEC 60947
Associated Fuse Rating :	10 A gG at <= 690 V conforming to IEC 60947
Net Weight :	0.045 kg
Connections - Terminals :	screw clamp terminals 1 0.34-1.5 mm²flexible with cable end \|\| screw clamp terminals 1 0.75-4 mm²flexible without cable end \|\| screw clamp terminals 1 1.5-4 mm²rigid \|\| screw clamp terminals 2 0.34-1.5 mm²flexible with cable end \|\| screw clamp terminals 2 0.75-4 mm²flexible without cable end \|\| screw clamp terminals 2 1.5-4 mm²rigid
Minimum Switching Voltage :	17 V
Tightening Torque :	1.3 N.m Philips No 2 \|\| 1.3 N.m pozidriv No 2
Width :	38 mm
Depth :	35 mm


Ambient Air Temperature For Operation :	-25-50 °C
Ip Degree Of Protection :	IP20 IEC 60529
Ambient Air Temperature For Storage :	-50-80 °C
Environmental Characteristic :	normal environment
Protective Treatment :	TC IEC 60068
Operating Altitude :	2000 m
