| Item ID |
|---|
| Title |
| Ambient temperature (operation) : | 0 … +55 °C |
| Ambient temperature (storage) : | -25 … +85 °C |
| Protection type : | IP20 |
| Ambient temperature (operation) : | 0 … +55 °C |
| Ambient temperature (storage) : | -25 … +85 °C |
| Protection type : | IP20 |
| Connection technology: field supply : | 6 x CAGE CLAMP® |
| Connection type 1 : | Field supply |
| Solid conductor : | 0.08 … 2.5 mm² / 28 … 14 AWG |
| Width : | 12 mm / 0.472 inches |
| Height : | 100 mm / 3.937 inches |
| Depth : | 69.8 mm / 2.748 inches |
| Color : | Light gray |
| Housing material : | Polycarbonate; polyamide 6.6 |
| Fire load : | 1.169 MJ |
| Signal type : | Voltage |
| Signal type (voltage) : | 24 VDC |
| Supply voltage (system) : | 5 VDC; via data contacts |
| Mounting type : | DIN-35 rail |
| Product Group Code : | 0015 |
| Packaging type : | Box |
| Country of origin : | DE |
| GTIN : | 4045454393731 |
