| Item ID |
|---|
| Title |
| ANSI : | C-73 |
| CSA C22.2 No. 42 : | File LR-406 |
| NEMA : | WD-6 |
| ANSI : | C-73 |
| CSA C22.2 No. 42 : | File LR-406 |
| NEMA : | WD-6 |
| Assembly Screws : | Steel, Zinc Plated |
| Blades/Contacts : | Brass |
| Body Material : | EPTR Rubber |
| Cord Range : | .245 - .700 |
| Product ID : | Ratings and NEMA I.D. permanently marked on device |
| Terminal Accom. : | 18-12 AWG |
| Country of Origin : | Mexico |
| RoHS Compliant : | True |
| Grade : | Residential |
| Series : | 515PV |
| Standards and Certifications : | UL/CSA |
| Flammability : | Rated V-2 per UL 94 |
| Operating Temperature : | -40°C to 60°C |
| Amperage : | 15 A |
| Current Interrupting : | Certified for current interrupting at full rated current |
| Dielectric Voltage : | Withstands 2000V per UL498 |
