15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light

Item ID #GFTR1W

Leviton

15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light

Name: 15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light
Brand: Leviton
SKU: GFTR1W
Price: 45.14 CAD
Availability: OutOfStock

Item ID #GFTR1W

Specifications

See all specifications

Applicable Standards and Certifications :	UL\|CSA\|CSA C22.2 No. 144\|CSA C22.2 No. 42\|Fed Spec WC-596\|UL 943\|UL 498
NEMA :	WD-1 and WD-6
Body :	Thermoplastic

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

15 Amp, 125 Volt Receptacle/Outlet, 20 Amp Feed-Through, Tamper-Resistant, Self-test SmartlockPro GFCI, Monochromatic, back and side wired, nylon wallplate/faceplate, screws and self-grounding clip included - White

Recommended tools

Standards and Certifications


Applicable Standards and Certifications :	UL\|CSA\|CSA C22.2 No. 144\|CSA C22.2 No. 42\|Fed Spec WC-596\|UL 943\|UL 498
NEMA :	WD-1 and WD-6

Description
Resources
Specifications

15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light

Item ID #GFTR1W

Leviton

15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light

Item ID #GFTR1W

15 Amp, Self Test, Tamper-Resistant Slim GFCI Outlet with LED Indicator Light

Specifications

See all specifications

Applicable Standards and Certifications :	UL\|CSA\|CSA C22.2 No. 144\|CSA C22.2 No. 42\|Fed Spec WC-596\|UL 943\|UL 498
NEMA :	WD-1 and WD-6
Body :	Thermoplastic

Available quantity000

Your price

$0.00 / Each

Add to template

Product Description

Recommended tools

Standards and Certifications


Applicable Standards and Certifications :	UL\|CSA\|CSA C22.2 No. 144\|CSA C22.2 No. 42\|Fed Spec WC-596\|UL 943\|UL 498
NEMA :	WD-1 and WD-6


Body :	Thermoplastic
Face :	Thermoplastic
Grounding Screw :	#8 Galvanized Steel
Line Contacts :	Brass
Mounting Strap :	Galvanized Steel
Self-Grounding Clip :	Yes
TR Shutter :	Thermoplastic
Terminal Clamps :	Brass
Terminal Screws :	#8 Plated Steel


Product ID :	Ratings are marked on device
Termination :	Back and Side Wire
Torque Range :	14-18 lbs.
Wire Accomodation :	#10 - #14 AWG Copper, #10 - #12 Copper Clad


Country of Origin :	China
RoHS Compliant :	False


Brand :	SmartlockPro
Color :	White
Device Type :	Duplex Receptacle/Outlet
Feature(s) :	Indicator Light, Self-Test, Tamper Resistant
Grade :	Residential/Commercial Specification Grade
NEMA Configuration :	5-15R
Product Type :	GFCI


Amperage :	15 A
Dielectric Voltage :	1250 VAC
Grounding :	Self-Grounding
Horsepower Rating :	1 hp
Pole(s) :	2
Power Supply Input and Frequency :	125V, 60Hz
Short Circuit Current Rating :	10 kA
Temperature Rise :	Max 30°C
Trip Level :	Class A
Voltage :	125 VAC
Wire(s) :	3
