| Country of Origin : | Viet Nam |
| Length : | 1.245 in |
| Height : | 4.542 in |
| Width : | 5.879 in |
| Program Options : | Programmable - 7 Day, 5+1+1 Day or Non-Programmable |
| Program Periods Per Day Options : | 4, 2, None |
| Stages Heat/Cool : | Single Stage or Heat Pump - Single Stage 1H/1C Heat Pump 2H/1C |
| Style : | Horizontal |
| Terminals : | RC, RH, C, W/E, Y, O/B, G, L, 6, +, S, - |
| 3-Wire Zone Valve Connections : | Yes |
| Millivolt Compatible : | Yes |
| Economizer Connections : | No |
| Humidity Control : | No |
| Heat Pump Dual Fuel Control : | Yes, Logic Option - No Sensor Required or Outdoor Sensor Option - Outdoor Sensor Provides Outdoor Temperature Setting to Lockout the Heat Pump and Switch to Gas Heat |
| Heat Pump Auxiliary Lockout Control - Outdoor Sensor Option : | Outdoor Sensor Provides Outdoor Temperature Setting to Lockout Auxiliary Heat |
| Product Family : | Blue Series 12 Inch Touchscreen Thermostats |
| Replacement Type : | Universal Replacement |
| Color : | White |
| Display Type : | 12.0 in. |
| Fan Options : | Auto|On|Programmable Fan|Circulating Fan |
| Power Source : | Battery|Hardwire|Power Sharing |
| Program Style : | 7 Day, 5-1-1 Day Programmable or Non-Programmable |
| Program Periods Per Day : | 4, 2 or None |
| Service Reminders : | Filter Change Reminder |
| Stages : | Single Stage 1H/1C, Heat Pump 2H/1C |
| System Type : | Single-Stage|Heat Pump |
| System Switch : | Heat-Off-Cool-Auto |
| Thermostat Branding Available : | ContractorBranding |
| Terminals : | RC,RH,C,W/E,Y,O/B,G,L,6,+,S,- |
| Voltage : | 24 Vac |
